Lever Wire Connectors
■ Accept conductors 0.2 ~ 4.0mm²
■ Re-usable and for use with solid,stranded and flexible conductors
■ Polycarbonate (PC), Flame-retardant shell to UL 94V-2 housing.
■ Polyamide(PA) levers.
■ A transparent shell inserts the wire, and the insulation is stripped properly
■ Rated to 600V max. for building wiring and 1000V max. signs or luminaires.
■ UL 486C Listed 、IEC/EN60998 and GB/T13140 Certified.
■ Suitable for lighting wiring, and building hydropower engineering electrical wiring boxes
File Name
Colour
Number
Specification
Wire Size
Packing Unit
Controls
PC622
Orange
2
32A, 450V, T85°C
600V, 105°C (221°F)
600V, 105°C (221°F)
0,2-4,0mm² , Rigid/Flex
28-14 AWG, Sol/Str
12 AWG, Sol
28-14 AWG, Sol/Str
12 AWG, Sol
100/ box, 5,000/ box
(10 bags,500/ bag)
(10 bags,500/ bag)
PC623
Orange
3
32A, 450V, T85°C
600V, 105°C (221°F)
600V, 105°C (221°F)
0,2-4,0mm² , Rigid/Flex
28-14 AWG, Sol/Str
12 AWG, Sol
28-14 AWG, Sol/Str
12 AWG, Sol
100/ box, 5,000/ box
(10 bags,500/ bag)
(10 bags,500/ bag)
PC625
Orange
5
32A, 450V, T85°C
600V, 105°C (221°F)
600V, 105°C (221°F)
0,2-4,0mm² , Rigid/Flex
28-14 AWG, Sol/Str
12 AWG, Sol
28-14 AWG, Sol/Str
12 AWG, Sol
50/ box, 3,000/ box
(10 bags,300/ bag)
(10 bags,300/ bag)
